Product Details
＋
MS Power MSD403R18M1, Rectifier Diode 400 Amp, 1800V, M16 x 1.5, Anode stud
Features
- Full blocking capability over wide temperature range
- Hermetic metal case with glass insulator
- Threaded stud
Applications
- Power Supplies
- Uncontrolled Rectifiers
- Oil Cooled Circuits
- Battery Chargers
Specification
| MS Power Part Number | MSD403R18M1 |
| Vrrm | 1800V |
| Diode Configuration | Anode Stud |
| IF(av) @ 100 Deg C | 480 Amp |
| IF(av) @ 120 Deg C | 400 Amp |
| Itsm | 9.2 kA |
| VF(to) | 0.85V |
| Tj(max) | 180°C |
| rF | 0.51mΩ |
| Termination Style (Tail) | 10.6mm Round Lug |
| Termination Style (Stud) | M16 x 1.5 |
| Tail Length to Stud | 200mm |
| R th(j-c) | 0.13°C/W |
| R th(c-h) | 0.04°C/W |
| Weight | 250g |
| Mounting Torque | 26 Nm |
| Factory Pack Qty | 8 |
| Country Of Origin | China |
| MS Power Headquarters | Germany |
